Liquid Cooled Silent Diesel Generators Model Ee483t

Technical Specification:
Engine Make : VECV
(Volvo Group & Eicher Motors JV)
Engine Model : EE483TC
Cooling System : Liquid cooled
Engine Power (BHP) : 38
Speed (RPM) : 150
Engine Prime Power (KW) : 28.34
Block Loading : > 60%
No of Cylinders : 4
Average Fuel consumption : @75% in Litres /hr5.5
Cylinder Arrangement : Vertical In-Line
Aspiration: Turbocharged Intercooled Combustion system Direct Injection Governor class / type A1 / Mechanical
Starting System : 12V DC
Electrical Bore x Stroke (mm) : 100 x 105
Compression Ratio : 17:01
Coolant capacity : In Litres 15
Fuel Type: High Speed Diesel
Lubricating Oil Specification: API CI4 Plus - SAE 15W 40
Lubricating Oil System Capacity (Litres): 13
Service Interval: 500 hours or 1 year
Alternator: Leroy Somer
Output of the Alternator (KVA): 30
Power Factor: 0.8
Voltage (V): 415
Phase: 3
Line Current in Amps: 41.7
Frequency in Hz: 50
Speed in RPM: 1500
Ambient Temperature in deg C: 40
Duty: S1
Type of Alternator: Brushless
Class of Insulation: HIP rating 23
Battery: Tata Green
Number of Batteries: 1
AH: 80
DG Set: DPK
Door Lock: Stainless Steel
Hinges: Stainless Steel
Fuel Filling: Lockable External Fuel Filling
Fuel Level Percentage Indicator: External LED Display
Diesel Filling Can: 35 liters can
Funnel for Diesel Filling: MS Powder Coated
Emergency Switch Off: External Push Button
Sound Level (dBA): <75
Genset Dimension (LxWxH) in mm: 2300 x 1000 x 1620
Fuel Tank Capacity (Litres): 95
Genset Weight (kg): 1350
Warranty: 2 years or 5000 hrs
