Robust Drum Walk Behind Vibratory Roller

Drum Walk Behind Vibratory Roller are used to handling the material, A very useful device for compaction after filling murmur, Various models are available as per requirement.This roller is widely used for construction for repairing of roads and highways etc.
Specifications
Prime Move
Multipurpose 7.5 Kva, Generator, (8 HP diesel high speed engine)
3 HP (3 PH) Electric motor (traction)
Heavy Duty Gear Box
Reverse- forward.
Vibratory Unit
1 H.P. (3 PH) x 1400 RPM electric motor
Speed
3 km/ hr
Electric
5.5 Kva (Output)
Extra electric point provided for other activities when roller not in use
Size
L- 2700 mm x W-1250 mm x H- 1300 mm
Earth Compactor
A very useful device for compaction after filling murmur, Various models are available as per requirement.
Mini Earth Compactor: EC-1
Earth Compactor: EC-2
Size
580 x 470 x 630 x 8 mm.
800 x 500 x 850 mm.
Prime Mover
Petrol / Kerosene engine
5 HP air cooled Lambardini engine
Electri
2 H.P. x 1 PH
5 H.P. x 3 PH
Compaction
2 tonnes
3-4 tonnes
Travel Speed
8 mtr. per minute
12 mtr. per minute
Plate Thk.


8 mm.


10 mm.
