Rf Level Switch - Ceramic & Ptfe Insulation, 450°c Max Temp, Grey & Blue | Immune To Material Deposition, 2 C/o Relay Outputs

We are known for manufacturing, exporting and supplying RF Level Switches for ESP Hopper to our clients in Pune, Maharashtra, India.

SMARTsaa make Level Measurement Switch from Pune, Maharashtra, India that is used for sensing the level of solids and liquids like Coal Ash, Fly Ash in ESP hoppers as well as cement, lime, iron ore, food stuff, milk powder, flour, salt, plastic granules, salt and most of the clear and viscous liquids.

SMARTsaa offers range of RF Level Switches with special ceramic and PTFE insulation for measuring level of fly ash in ESP hoppers and level of coal ash in silos.
As fly ash has bulk density of approx 1000 Kg/ m3, level measurement is very critical. By using SMARTsaaRF, level of coal ash is monitored effectively and accurately.
Special sensors with Ceramic coating for areas where temperature can reach up to 450 degrees and PTFE coating where temperature can reach up to 200 degrees are developed.
The protective coating makes it abrasion resistant and enhances life of probe. Special Coat guard circuit makes this probe immune to the deposition of thin layer of material on probe. The working does not get affected due to coating or deposition.
Control Circuit can be integral with sensor probe or it can be mounted remotely if temperature at the product is higher than 100 degree cent.
This level switch is suitable for highly dusty environment. It is also simple to install and easy to maintain.

Ambient temp can be up to 0 to +60 deg for standard models, special models for fly ash where temp is more are having PTFE and ceramic coating.

Technical Specifications:-
Type: SMARTsaaRF
Control Supply: 230 V AC / 110 V AC / 24 V DC
Rod Length: Customer specific
O/P: 2 C/O relay contact rated for 5 Amp resistive at 230 V AC
Enclosure for control unit: Cast Al, IP 65
Max working temperature: Control unit: 60 degree cent max, standoff or remote arrangement is recommended by which control unit is taken away from hot area.
Process Temp: Up to 200 degree cent for PTFE probe and 450 degree cent for ceramic probe
With selector switch to program switch at site for bottom level or top level monitoring.
