Membrane Level Switch - Cast Aluminum, Ip 40, Flanged Mount | Reliable Point Level Detection, Over-pressure Protection, Non-intrusive Design

We are identified as one of the most competent enterprises of this industry, engaged in manufacturing, exporting and supplying a wide range of Membrane Level Switches from Pune, Maharashtra, India. We offers Membrane / Diaphragm Level switch for measuring level of free flowing and dry material like food grains and powders and bulk goods. APPLICATION: Sensing clogging of material on screw conveyor Boot level detection of bucket elevator Detect level of food grain in hopper Level detection for bulk goods Detects bin overflow and maintain a pre-determined material level Can be used as Chute Block Device OPERATING PRINCIPLE: The pressure of the product on the membrane operates a limit switch inside the switch compartment. The contact of limit switch is used for control action. FEATURES: Point level switch Low cost but Reliable No power supply required Installation is simple. Flush mount, non-intrusive Ideally suited when vessel size or internal clearance is limited or where protrusion into a vessel is not acceptable Over-Pressure Protection SPECIFICATIONS: Enclosure : Cast Al, IP 40 O/P : 1 C/O relay contact rated for 15 Amp resistive at 230 V AC Mounting : Flanged Pressure for detection : Approx 2 N min. Normal Sensitivity: 60 gm Operating Temp : 10 - 80 degree Cent Diaphragm Material : SS / Neoprene Rubber Particle Size : up to 30 mm and a density of 0.3 to 2.5 g/cm3
