Polarizing Microscope Etms-141 - Monocular Inclined, 50x To 400x Magnification | Built-in Halogen Illumination, Strain-free Plan Achromatic Objectives, Diposable Compensatory Slot

Polarizing Microscope Etms-141 - Monocular Inclined, 50x To 400x Magnification | Built-in Halogen Illumination, Strain-free Plan Achromatic Objectives, Diposable Compensatory Slot

Get Latest Price

Minimum Order Quantity :

1 Piece

Brand Name :

Edutek

In Stock

Product Specifications

Focus System	Coaxial coarse and fine focusing system
View Head	Trinocular; 30Adeg inclined, 360Adeg rotatable
Spare Parts	Replacement halogen lamp, fuse, dust cover, spare eyepiece
Features	Rotatable analyzer, polarizer, Bertrand lens, quartz wedge, design for geology/petrography
Theory	Other, Polarizing light microscope for optical mineralogy and petrographic analysis.
Drawtube	Trinocular
Sensor	Not applicable/Not equipped for built-in digital imaging
Resolution	Not specified; determined by optical system
Interface	Standard mechanical tube, optional camera interface adapter
Frame Rate	Not applicable for optical observation
Focal Distance	75mm (approx.)
Magnification	40X to 600X
Dimensions	Approx. 220mm x 360mm x 430mm
Focus Range	Coarse and fine adjustment; typically 28mm coarse, 0.2mm fine
Eyepieces	Wide field 10X paired, with crosshair; interpupillary adjustable
Eyepiece Tube	30Adeg inclined, 360Adeg rotatable trinocular head
Illumination	Transmitted light, halogen lamp 6V/20W with intensity control
Coarse Adjustment Range	28mm
Fine Adjustment Range	0.2mm
Working Stage	Rotating mechanical round stage with graduations, 360Adeg rotation
Still Image Capture Resolution	Optional, depends on attached camera
Video Capture Resolution	Optional, with suitable camera attachment
Image Format	Optical only (standard model); optional camera port for digital capture
Interpupillary Distance	55-75mm, adjustable
Objective Achromatic	5X, 10X, 40X (S), 60X (S), Color-coded, Rotatable nosepiece
Condenser	Abbe condenser, N.A. 1.25, Center adjustable, Strain-free
Light Source	Halogen 6V/20W, Kohler illumination system
Payment Terms	Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
Sample Available	Yes
Sample Policy	Sample costs shipping and taxes has to be paid by the buyer
Packaging Details	carton box, export quality also available
Main Export Market(s)	Asia, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market	All India
Certifications	ISO 9001, 14001 ,CE
