Plug Torque Tester

Plug Torque Tester is for compliance is checked by engaging the device, as during intended use, with the socket-outlet of a test apparatus. Plug Torque Tester is a device provided with pins intended to be introduced into fixed socket-outlets shall not impose undue strain on these socket-outlets.
The balancing arm of the test apparatus pivots about a horizontal axis through the centre lines of the contact tubes of the socket-outlet at a distance of 8 mm behind the engagement face of the socket-outlet.
With the device not in engagement, the balancing arm is in equilibrium, the engagement face of the socket-outlet being in the vertical position.
After the device has been engaged, the torque to be applied to the socket-outlet to maintain its engagement face in the vertical plane is determined by the position of a weight on the balancing arm. The torque shall not exceed 0,25 Nm.
Load: 0.5N*2/1.25N*1/0.25N*1
Plug: UL plug*1, Australia plug*1,all-purpose plug*1
Conforms to standard: IEC60884,VDE0620,IEC60598,IEC60065Fig11
