Plastics Impact Testing Machines

These Plastics Impact Testing Machines are mainly used for determining the rigid plastics, strengthen the impact toughness of nonmetallic materials such as nylon, glass fiber reinforced plastic, pottery, cast stone, plastic electric apparatus, insulating material.
These machines can be operated semi-automatically. They are essential testing instruments for quality testing section, university and college, research institution and industrial and mining enterprise. The machine can do the test according to ISO179, GB/T1043, GB1834, JB/T8762, ASTM D6110, ASTM 5942 and ISO9854, etc.

Parameters of XJJ-5S
Impact energy 0.5, 1, 2, 4, 5
Impact speed (mm/S) 2.9
Pendulum moment:
Pd0.5=0.2679 Pd1.0=0.5358 Pd2.0=1.0718
Pd4.0=2.14359 Pd5.0=2.6794 Pd7.5=4.0192
Pd15=8.0385 Pd25=13.397 Pd50=26.795

Raising angle 150A
Impact center distance (mm) 230
Standard Sample span 40, 60, 62, 70, 95
Power supply 1 Phase, 220V, 50Hz/60Hz
Dimension 600A 450A 1300 mm
Weight(Kg) 85kg

Features:
*Multi Pendulums (big and small) and Multi scale reading for each testing machine which enlarge the test range of energy.
*Pendulum impact is realized as automatically by control button.
*Sample and support are easy centering.
*Electromagnetic clutch hold the rasing pendulum. Power sudden off still in safety.
*Digital LCD screen control and value showed.
