Pgcoders - Absolute

Absolute shaft encoders ENA-8, ENA-9 are electrical transducers, the output of which represents absolute position of the shaft. It is in natural Grey, Binary or BCD format available upto 9 bits (512 steps per turn). Unlike Incremental encoders, each step is exclusive; the digitally defined shaft position, which is not affected by power outage.

Ranges above 9 bits are complemented by German make single & Multi turn absolute encoders. These are available upto 17 bits in single turn and maximum 17 x 12 bit Multi turn encoders in various versions.

Used extensively in automation industry and robotics where mechanical position is to be retained regardless of noise or power outage.

Indigenous
A. ENA-9 in standard 58mm diameter
A. Available upto 512 steps per turn
A. Shaft diameter 10mm
A. With LATCH and F/R facility
A. Voltage level 10-30V
A. Signal conversion transducers available

German make
A. Upto 1,31,072 steps per turn
A. Upto 17 bit steps per turn & 4096 turns
A. With SSI, PROFIBUS, CANBUS outputs
A. Voltage level 11-32V
A. Special cable for SSI line available
