Multi-functional High-speed Mounter (Skm-898-12) - Stainless Steel, 1570x1400x1400mm, 50000cph | Maglev Linear Motors, 3-camera Vision System, Automatic Process

We are engaged in offering excellent quality Multi-Functional High-Speed Mounter (SKM-898-12) to our valuable clients.
a c Speed: 50000CPH

a c Features
1a Maglev linear motor:
Aa 1400Wi Maxi maglev linear motor used for driving the X axis
Ba 700Wi Maxi maglev linear motor used for driving the Y axis
Ca the Xa Y axises are controlled by closed-looping feedback with the linear grating ruler
Da 12 sets of linear motor driving axises
Ea capable to mount 0402~30mm components
2a 3 sets of camera and light source
Aa 1 set of 300,000 pixel digital camera is used for PCB marks recognition
Ba 2 sets of 1i 400,000 pixel digital camera is used to identify and position the components
3a Original imported PC
4a Two sets of USB I/O modules
5a Japanese SMC Air-driving componentsi except feeder driveri
6a Twelve sets of 360A rotating main axises
7a A variety of components can be mounted: resistorsa capacitorsa LED (i 30mm*30mm)a BGAa QFPa CFPa I BGA

Parameters:-
Dimension:-
Length : 1570mm
Width : 1400mm
Height : 1400mm
Total Weight : 1300kg

PCB:-
PCB Length*Width : Min: 60mm*60mm
Max:1200mm*330mm
PCB Thickness : 0.5a 3.0mm

OS
PCB Clamping : Edge damping
Software : Windows XP
Display : LCD monitor
Input Device : Mousea keyboard
Vision System : No. Of Camera 3 sets: i 1 set: 300,000 pixel; 2 set: 1,400,000 pixeli
Mark Points Recognition : Gray scale and pattern matching & Edge Detection
Mounting Precision : A 0.06mm chip & IC
Mounting Speed : 50000CPH (12 nozzles)
Power : 220 ACa 50 Hz
