Metal Analyzer

Metal Analyzer

EDX 3600 carries five characteristics of EDX family: rapid, accurate, non-destructive, intuitive, and environment friendly.

Features
1.Automatic Multi collimator and filter switching.
2.Triple safety protection mode
3.Independent matrix effect correction model
4.Multi variant non-linear regression procedure
5.Arbitrary optional analysis and identification model
6.Electric circuit unit with high signal to noise ratio
7.High efficient X-ray tube
8.Professional X-ray fluorescence analysis software for Full element measurement
9.Signal - Noise Enhancer (SNE)

Configurations
Mobile sample plateform.
Signal-to-Noise Enhancer.
SDD / Si Pin Detector.
Digital multi-channel analysis system.
High power x-ray tube.

Specifications
X-ray Source :X-ray Tube Ti or W cathode
HV Generator :50kv adjustable in 200V steps
Current adjustable in 1mA steps
Detector : SDD / Si Pin
Detection Range : S(Z=16) to U(Z=92)
Measurement Range : 0.1 - - - 99.99 %
Measurement Time : 30 - - - 300 seconds
Measurement Precision : A 0.1% In homogeneously melted Sample ( Accuracy levels in comparison with fire assay result only )
Collimators and Filters : 8 Collimators and 5 Filters automatically switched as per requirement
Working Temperature : 5 - 50 A C
Relative Humidity : 0 - - 95%
System Requirement : External PC with Windows XP / Windows 7 (32bit)
Software : Windows Based
Power Requirement : 230V - 50Hz
Power Consumption : 100W
Instrument Dimension : 550 mm x 410mm x 320mm
Weight : 45Kg
