Salient Features of Universal Milling Head :-
* It has infinite spherical contouring capability since the spindle axis can be set in any angle, at any degrees and at any plane - at circular planes or at oscillating plane or at a combination plane of both circular and oscillating positions. It tilts A 360A around the machine spindle axis; it tilts A 360A on its own spindle axis and it oscillate from front to back.
* The head consists of 2 pairs of spiral bevel gears and 3 rotating shafts provide 360A & 3 housings one for spindle, the second for the central module & and the 3rd for the mounting flange.
* The flange module and central module have circular T slots, so that the spindle module can tilt on the central module & the central module can tilt on the flange module.
* The spindle, having IS0-40 or ISO-50 taper. Gears, shafts, spindles are made of case hardened steel, case hardened and ground. The body, consisting of 3 modules, is made of stress-relieved cast iron. The spiral bevel gears get located in the shafts/spindles through adequately dimensioned & ground splines. Graduated collars with 1A least count are provided on the spindle and central module.
