Load Scheduler

The Digitech Load Scheduler LDS 03 is a microprocessor based instrument to control the load dispatch from a distribution transformer. The unit accepts 3 Phase input and may be programmed to schedule deliver output to three consumers.
The on/off time of each consumer may be programmed through a dongle. The program (schedule) is loaded in the unit as soon dongle it is inserted.
The dongle may be programmed at office through window based software and programmer.

The load schedule is rotated on weekly basis automatically. The real time programming and load scheduling is also possible through key board provided within unit.

Built-in memory is provided for data retention after removal of the dongle and during power failure. Stored data may be transferred to PC through RS-232C link on command also. Unit may be mounted on pole itself near the transformer.

SPECIFICATIONS
Type: Microprocessor based.
No of channels : 3.
Capacity : 10HP to 25 HP each.
Display : 16x1 intelligent LCD display.
RTC : Built-in
Programming : By smart dongle.
Serial Port : RS232C Provided.
Power: 440VAC, 3Phase , 4 wire.
