Leather Low-temperature Flexing Tester

Price:

Get Latest Price

Minimum Order Quantity :

In Stock

Product Specifications

Application	For determining the flex resistance of leather at low temperatures
Interface Type	Touch panel/Keypad
Response Time	< 1s
Display Type	Digital LED/LCD display
Frequency	50Hz
Accuracy	1%
Operating Voltage	220V
Number of Specimens	6 (simultaneous testing)
Power Supply	220V AC, 50Hz
Gas Pressure	0.5~0.7 MPa (only if pneumatic type)
Temperature	-30C to +30C (adjustable)
Port Size	Standard 8 mm Coupling
Automation Grade	Semi-automatic
Equipment Type	Leather Low-Temperature Flexing Tester
Features	Microprocessor controlled, programmable test cycles
Max Height	400 mm
Test Range	-30C to +30C
Mounting Type	Bench-top
Resolution	1 cycle
Humidity	30% - 85% RH
Specimen Size	70 mm 45 mm
Measuring Range	0-10,000 cycles
Usage	Testing flexibility of leather or similar materials under low-temperature conditions
Capacity	6 stations
Machine Weight	Approx. 60 kg
Test Speed	100 cycles/min (adjustable)
Test Width	70 mm
Test Stroke	60 mm
Control Mode	Digital Control with Timer
