Integral Warp Rebeaming Machine
Price:
Get Latest Price
In Stock
Product Specifications
| Work Width | Customizable |
| Beam Flange Diameter | <800Mm |
| Warping Speed | 0~400M/Min |
| Beaming Speed | 0~80M/Min |
| Warping Motor Power | 7.5Kw |
| Total Weight | 7500Kg |
| Features | High Speed, Precise Warping, Efficient Beaming, Automatic Control, Durable Design, Easy Operation, Customizable, Improved Quality |
Product Overview
Key Features
Integral Warp Rebeaming Machine
Scope of Application
Develop new products in the silk/chemical twisted filament weaving, yarn dying, towel weaving and other industries. This machine can work with imported water-spraying, rapier, rib and other shuttleless looms for pre-weaving process. It is widely used in the industrial fabrics industry.
Technical Specifications
| Work width | Particular specification can be customized according |
| Beam flange diameter | < 800(mm) |
| Warping speed | 0 ~ 400(m/min) |
| Beaming speed | 0 ~ 80(m/min) |
| Deviation of linear speed | <+ 2%( 300m/min ) (With a speed of 300m/min) |
| Braking distance | < 3(m)(500m/min) |
| Drum diameter | 1026 |
| Cone Length | 1010 |
| Cone angle | 9o |
| Stripe traverse speed | 0.001 ~ 9.999(mm/r) (No grade) |
| Deviation of stripe traverse | 0.2% |
| Deviation of stripe positioning | Adjustable |
| Distance between space reed and yarn on the drum Stripe location | Automatic |
| Stripe location | Automatic |
| Stripe width | 0.1 ~ 999.9(mm) (The length should not be longer than the guide roller) |
|
|
|
| Spindle space | 300x250(mm) (Wool yarn/ cotton yarn) |
| Spindle number | 290x290,220x220(mm) (Chemical fiber) |
| Input voltage | 3X380V- 10% |
| Capacity | 20KVA |
| Warping motor power | 7.5KW |
| Beaming motor power | 11mw |
| Strip traverse motor | 0.75KW |
| Warping and beaming frame weight | 5000(kg) / (YBGA528B:5500kg) |
| Creel weight | 2500(kg) |
