High Quality 4 Axis Cnc Cutter

We are offering our customers a wide range of High Quality 4 Axis CNC Cutter, which is available in following Specifications :-
Model Robozz : 1225
X,Y,Z ,A axis working area : 1200*2500*600mm*180degree
Whole structure : Welded Steel gantry structure
X,Y,Z structure : Taiwan HIWIN Square linear guide rail
X,Y structure : Rack and pinion transmission, high speed and more stable;Y -double motor drive
Z structure : Imported ball screw, high precision
Max. idling speed : 50m/min
Max. working speed : 25m/min
Repositioning Accuracy : A 0.05mm

Application:-
It is very suitable for making deep foam, plastic, stone, wood mould works. surely also can widely used for flat materials such as flat stone, wood, aluminum, copper, PVC and other hard and soft materials.

SPECIFICATIONS
1.4 axis cnc cutter/cnc router
2.z axis height 400-700mm
3.spindle rotate 180 degree
4.optional rotary device

Application industry
1. Decoration Industry
2.Mould Industry
3.Craft Industry
4.Advertising Industry
5.Furniture Industry

Features:-
1. Lathe bed adopts strong welded steel tube to avoid distortion.
2. Spindle rotate 180 degree,you can make 2d 3d engraving on curved surface, arc-surface, bending surface, larger dimension mould, statues, sculptures, cylinders...
3. 400mm-700mm height Z axis to burden heavy and thick materials
4. Servo motor and driver
5. 4 axis control system
6. Optional rotary device for cylinders, large statues, sculptures, complexity moulds processing.
