Helmholz Digital Input Module - 16 Inputs, 24 Vdc, Hot-pluggable | Reverse Polarity Protection, Led Indicators For Operating Status And Input States

We are engaged in exporting, distributing and supplying excellent quality Helmholz Digital Input Module DI16 x 24 VDC to our valuable clients.
General characteristics
- 16 inputs (electrically isolated from the backplane bus)
- 24 VDC input voltage
- Can accommodate two-wire proximity sensors
- A blue LED indicates the modulea s operating status
- Green LEDs (one for each input) indicate the inputsa states

Technical data/Ordering data
Digital Input Module: DI 16 x 24 VDC
S/N: 600-210-0AP21
Number of inputs: 16
Electrically isolated from backplane bus: Yes
Channels electrically isolated from each other: No
Current draw
- External: Max. 0 mA
- Internal: Max. 23 mA
Power dissipation: Max. 3.7 W
Input characteristic curve: Type 2, EN 61131-2
Reverse polarity protection for inputs: Yes
Input voltage
- For low signal (a 0a ): -3 V to 9 V
- For high signal (a 1a ): 12 V to 30 V
Hot-pluggable: Yes
Dimensions (H x W x D): 110 mm x 25 mm x 73 mm
Weight: Approx. 110 g
