Head Seat Cutting Machine

We are well-known manufacturer, supplier and exporter of a range of Head Seat Cutting Machine in Rohtak, Haryana, India available with following details:

Specifications:

TECHNICAL RECORDSMV 2 & 6
Spindle65 mm
Maximum Spindle Travel150 mm
Maximum Spindle Slant30 degree
Distance From Table to Spindle410 mm
Minimum Seat Cutting Dia14 mm
Maximum Seat Cutting Dia60 mm
Spindle Speed (Variable)50-300 rpm
pindle Head Travels(front and back)60 mm
Spindle Head Travels(left and right)850 mm
Clamping Block Travels(front and back)150 mm
Clamping Table Size600A 1100 mm
Electricals Requirements3 phase,5 amp,1 hp
Air Requirements100 psi 6 bar
Spindle Motor0.75 kw/1 hp
Floor Space Requirement1300 mmA 1000 mmA 2200mm
STANDARD ACCESSORIESMV 2 & 6
Air Gun Set1 no
Allen key Set1 set
Digital Centering System-Imported1 no
Single Cylinder Clamping Platenill
Guide Stem -Steel10 no
Cutting Tool(45 degree)-Imported2 no
Cutting Tool(30 degree)-Imported1 no
Chamfering Tool(45 degree)-Imported1 no
Phasing Tool (90 degree)-Imported1 no
Ball Head(cutting holder)-Imported(.236)1 no
Ball Head(cutting holder)-Imported(.375)1 no
Tip Holder-Imported 14-251 no
Tip Holder-Imported 24-401 no
Tip Holder-Imported 40-601 no
Spanner 22-241 no
Tool Setting Fixture-Imported1 no
Cutter Blade Removel Screw Driver-Imported1 no
Stainless Steel Spring6 no
Pb Bush6 no
Lifting Hole Cover1 set
Job Support Plate2 no
