Fully Automatic Pick And Place Machines By Drive Technologies

Fully automatic placing.
Automatic fiducial correction and bad mark sensing.
Automatic change of nozzles.
Component range from 0402 to PLCC 84 from all current packaging.
Modular construction and efficient WINDOWS based control system.
Pick and place data either by TEACH IN or from various CAD data
Excellent price to performance ratio.

Technical Specifications

PCB Placement area: Max 300X500 mm
Component
Range : from 0402 to 30x30mm
Pitch : upto 0.5mm
96 feeders for 8 mm or 80 tape feeders+26 stick of SO8-So16
Component packing
Tapes : 8,12,16,24 & 32 mm
Sticks : SO8-PLCC84
Trays
Placement rate : 2000-3000 cph
Nozzle changer
Automatic,5 Nozzles
Automtaic sensing of nozzle presence
XY resolution
50.8 mmm,Standard
25 mmm with optional linear encoders
Vision System
Automatic Fiducial Correction
Automatic Bad mark sensing
Component orientation
1A Steps
