Log Roll Rewinding Machine - Voltage: 415 Volt (V)

Applications: For making Log Rolls of various lengths from Jumbo Rolls Specifications: Working Width : 1650mm Parent Roll Dia. : 800mm max Finish Roll Dia. : 250mm max. on 76mm ID cores Unwind Station: Integral with machine frame (rear loading) with Air Expansion Shaft suitable for 76mm ID cores. Motorised Axial Movement Pneumatic brake Pneumatically operated pressure lay-on roll Hydraulic lifting arrangement for mounting jumbo rolls Rewind Station: Rewinding on Twin Air Expansion Shafts fixed on a Single Turret, suitable for 76mm ID cores (cantilever type) Turret design facilitates rotation of Rewind Shaft in winding position only while the second Rewind Shaft remains free. Rewind through separate Auto Tension Control Drive. Turret rotation and shaft locking at free end through pneumatic system. Pneumatically operated rubber Lay-on Roll on Rewind Shaft. Wrapping Roll on free Rewind Shaft for wrapping loose end. Speed : 200 metres per minute max Drive : 7.5 HP AC Variable Frequency Main Drive with Built-in Control Panel 3 HP AC Constant Auto Tension Drive for Rewind 0.25 HP AC drive for Wrapping Roll PLC Based HMI Controlled Panel Machine : Heavy Duty M.S. Fabricated Body Rubber sleeve Bow Roll Accessories : 76mm Air Expansion Unwind Shaft. - 1 no. Tool kit Safety features: 4 Emergency Stop push buttons on each side of the machine Full length Emergency Stop Kick Plate in front
