Fix Terminal

We are famously engaged as manufacturer, supplier and exporter of Fix Terminal in Foshan, Guangdong, China available with following details.

Specifications:
Name: Strain Relief Bushing (wiring accessories bearing accessories bearing bushing)
Material: the use of advanced engineering materials PA66 made of shell, fire rating 94-V2, high temperature resistance
Voltage: 300V
Applicable line: round wire flat wire can be used.
Model: KX4N-4/KX5N-4/KX6N-4/KX6N3-4/KX7N-2
Suitable for UL wire: SJT3C#18/ SJT3C#16/ SJT3C#14 SPT-2/SVI-SVT/
For wire size (mm): 3.71/3.8*7.6/6.4-7.4/7.6/8.2/9.2-10.5
Machine plate thickness F:1.9/1.8/1.6
Buckle line length (mm): 10.4/11/14.8/19.2
Packing: 1000/500/300 / bag, 6000/3000/1800 / box
Passed REACH, TUV certification.
The characteristics of shell for forming a senior engineering material PA66 will not crush. Formed inside the fixed connection, seismic pressure, joint fastness, increase the scope of wire Crimp make it easier to cable wire fixation, and more clamping wires, even if strong vibration or loss.
Usage: insert the line into the casing, and loosen the hand after the force is tightened.
Application: a variety of household appliances, electric motors, lighting and accessories, such as the connecting parts of the wire, such as electric fans, exhaust, lighting, fans, motors and other household wiring wiring equipment.
