Electro Dynamic Shaker

Brand - Tarang Kinetics Shine Force - 200 Kgf Max Acceeration Bare Table Sine - 50'g' Max Displacement Peak to Peak - 25 mm Axial Resonance - 3.5 KHz @ +- 5% Usaeful Frequency Range - DC to 3.8 KHz Mass of Armature - 4Kg Dia of Armature - 140 mm Insert Pattern - Center-1, 70pcd-4, 100pcd-4 Payload Capacity - 20 Kg Stray Magnetic Field - Less than 3m Cooling Blower - 300 cfm Shaker Mass - 700 kg Dimension - 580x410x530 mm Compresses Air Earthing - 4-6 bar Signal to noise ratio - greater than 70dB Power efficiency - greater than 90 % Input Impedance - 10 Kohm Input sensitivity - 4Vrms, compatible with all standard controllers Power requirement (3 Phase) - 3 KVA Protection interlocks - Over Current, Over Voltage, Under Voltage, Module Failure, Cooling Interlock, Over Temperature Ampli Standard Software - Swept Sine, Random, Classical Shock, Resonance Search Track & Dwell Optional Software - Random on Random, Sine on Random, Shock Response Spectrum, Transient Time history etc No Of Channels - 4 Channels upgradable upto 32 channels
