Door Closer Durability Testing Machine - Color: Blue

Test equipment function
Compliance with the latest standards: The equipment is designed in strict accordance with the latest standards EN 1154 and ANSI/BHMA A156.4, which can meet the performance test requirements of door closers.Four-station design: The vertical four-station design can test four door closers at the same time to meet the needs of batch testing and improve test efficiency.
PLC control and touch screen operation: Automatic control with PLC (Programmable logic controller), equipped with user-friendly touch screen interface, it is easy to set up test procedures, adjust parameters and monitor the test status in real time.
Pneumatic drive and flexible adjustment: The linear cylinder drives the swing arm, which can flexibly adjust the opening Angle and opening time of the door to meet different test needs.Independent control and non-interference: Each station is controlled separately, non-interference, to ensure the independence and accuracy of the test.Real-time monitoring and automatic shutdown: Equipped with sensors to monitor the test process in real time, when the sample of the door close fails, the equipment will automatically stop and prompt fault information.

Model: ZNEN1154-N
Frame: Heavy-duty steel tube with baking finish
Size: L 3.5 m W 1.3 m H 2.6 m
Operation Space: 3.5 m 3.5 m 2.6 m
Test Door Size: 916 mm 2000 mm
Door Opening Angle: 0A A ~ 90A A A A 5A A (adjustable)
HMI: 7A A A A touch screen
Pneumatic Parts: Airtac brand
Additional Test Function: Includes door closer overload test fixture
Test Standards: EN 1154, ANSI/BHMA A156.4
Test Doors: 4 test doors (40 kg; other door mass can be applied by user)
