Digital Macro Vickers Hardness Tester - 1hv-4000hv Hardness Range 100x Max Magnification | Automatic Load & Digital Lcd Display Built-in Printer

We are among the prominent names in the industry engaged in distributing and supplying of Digital Macro Vickers Hardness Tester in Ghaziabad Uttar Pradesh India.

i? Switch type of objective lens & indenter: Manual Turret

i? Test force: 1.961 4.903 9.807 19.61 29.42 49.03N (0.2 0.5 1

2 3 5kgf)

i? Max. height of test piece: 85mm

i? Depth of throat: 110mm

i? Scale : HV0.2 HV0.5 HV1 HV2 HV3 HV5

i? Conversion Scale : HRA HRB HRC HRD HRF HBW H15N H30NH45N H15T H30T H45T

i? Min. Measuring Unit : 0.01um

i? Hardness Value Rang : 1HV-4000HV

i? Hardness Value of Reading : Digital LCD Screen

i? Total Magnification of Microscope : 100X (For Observation) 200X (For Measurement)

i? Loading Method : Automatically (Load dwell and unload the testing force)

i? Duration Time : 1-99s

i? X-Y Testing Table : Dim.:100i? 100 mm Max. Travel Range: 25i? 25mm Moving Resolution Ratio:0.01mm (X-Y Digital Testing Table with digital LCD Screen for Optional)

i? Data Output : Built-in Printer (Hardness Value The Max. And Min. Value Testing times and Average Value) Built-in RS-232 interface

i? Power supply: 110V/220V + 5% 50/60Hz

i? Dimensions: 405 x 290 x 480mm

i? Weight: approx. 45kg

i? Data Output : Built-in Printer (Hardness value The max And min. value Testing time and average value Built-in RS-232 interface.
