Curing Tank - Double Walled Stainless Steel, 15 Cm Cube Moulds For 6/12/24/36 Moulds | Digital Temperature Controller, Warm And Boiling Water Curing Methods, Water Circulation System

CURING Tank (Accelerated) for 15 cm cube moulds 6 nos, fitted with DIGITAL TEMP. Controll;er cum Indicator

As per IS 9013 1978. It is developed to get the compressive strength of 28 days within short period by curing the concrete specimen by any of two methods namely warm-water method and boiling water method.

Double Walled. Outer Made of M.S. Inside made of S.S. With hinged Cover Lid. Long Heaters placed at the bottom. Can accommodate 6 / 12 / 24 / 36 moulds of 15 cm or 12 / 24 / 36 / 72 moulds of 7.06cm with concrete or mortar. Fitted with Microprocessor Based Dual Display Digital Temperature Indicator cum Controller. Temperature Range from 50 C to 100 C. Provided with water circulation arrangement to keep the temperature uniform. Overflow Nozzle is provided. Drain Cock for emptying tank is also fitted at the bottom. Operation on 230 Volts, Single Phase.

Curing Tank Accelerated for 06/12 cube moulds of 150/70.6 mm:

For curing 06 Nos. of 150 mm Cube Moulds or 12 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 230 V, 50 Hz, 32 Amp, Single Phase.

Curing Tank Accelerated for 12/24 cube moulds of 150/70.6 mm:

For curing 12 Nos. of 150 mm Cube Moulds or 24 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 440 V, 50 Hz, Three Phase.

Curing Tank Accelerated for 24/48 cube moulds of 150/70.6 mm:

For curing 24 Nos. of 150 mm Cube Moulds or 48 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 440 V, 50 Hz, Three Phase.

Curing Tank Accelerated for 36/72 cube moulds of 150/70.6 mm:

For curing 36 Nos. of 150 mm Cube Moulds or 72 Nos. of 70.6 mm Cube Moulds. Suitable to operate on 440 V, 50 Hz, Three Phase.
