Creep Testing Machines - Chromium Plated Steel Columns, 10 - 50 Kn Load Capacity | Stress Rupture Testing, Constant Load Test, High Accuracy
Share

Creep Testing Machines - Chromium Plated Steel Columns, 10 - 50 Kn Load Capacity | Stress Rupture Testing, Constant Load Test, High Accuracy

Price: 100 INR / Piece

Get Latest Price

Minimum Order Quantity :

1 Piece

Brand Name :

Teknik

In Stock

In Stock

Product Specifications

Operating Voltage230V AC
AccuracyA+-1% of full scale
Specimen SizeStandardized up to 25 mm diameter x 300 mm length
HardnessStructural Steel Frame, Rockwell 60 HRC
Measuring Range0 to 10 mm (Extensometer Included)
TemperatureAmbient to 1000AdegC
Product TypeCreep Testing Machines
Test RangeUp to 200KN
Mounting TypeFloor Mounted
Response Time<1 s
Automation GradeSemi-Automatic / Fully Automatic
Power Supply230 V AC, 50 Hz
Resolution0.001 mm
FeaturesAutomatic Data Logging, Overload Protection, PID Temperature Control
ApplicationStrength of Material Testing Equipments
Display TypeLCD Digital
Interface TypeRS232 / USB
Frequency50 Hz
Gas PressureAtmospheric to 10 bar
Port Size15 mm
Humidity10% - 98% RH
UsageStrength of Material Testing Equipments
Number of Specimens1 - 6
Max Height1800 mm
Capacity20KN, 50KN, 100KN (Custom Available)
Machine WeightApprox 175 kg
Test SpeedAdjustable, 0.5 to 50 mm/min
Test Width50-200 mm
Test Stroke0 - 50 mm
Control ModeDigital / Manual
Supply Ability100 Per Day
Delivery Time1 Week
Sample AvailableYes
Sample PolicySample costs shipping and taxes has to be paid by the buyer
Packaging Detailscarton box, export quality also available
Main Export Market(s)Africa, Middle East, Asia
Main Domestic MarketAll India
CertificationsISO 9001, 14001 ,CE

Product Overview

Key Features

Creep Testing Machines For engineering lab

Microteknik has developed Creep and Rupture testing machine using state of the art technology. It combines high accuracy with long time reliability, essential qualities for modern day creep and stress rupture testing.

Constructed for the discerning user, particularly those who appreciate the value of testing individual specimens, the model has a choice of load capacities: 50, 30, 20 and 10 kN. The Microteknik machine has four chromium plated steel columns and substantial upper and lower cross heads.

The load frame is supported by a completely enclosed robust base unit which has four corner leveling feet and a protective fabricated top cover. The upper cross head carries the lever assembly which includes a lockable counterbalance weight. There are hardened knife-edges at all fulcrums. By means of this lever arrangement, slotted incremental weights, carried by a weight pan/rod assembly, apply load through the test specimen. uses double lever and other capacity machine uses single lever arrangement.

Applications :
Creep testing at elevated temperatures
Stress to rupture
Stress relaxation
Constant load test in compression
