Compression Testing Machine Pillar Type Mtct-106a - Manual Load Application, High Stability Four Pillar Design, Pressure Gauge With Max Load Indicator
Price:
Get Latest Price
Minimum Order Quantity :
1 Unit
Brand Name :
Teknik
In Stock
Product Specifications
| Resolution | 0.1 kN |
| Equipment Type | Pillar Type |
| Mounting Type | Floor Mounted |
| Humidity | a%0$?85% RH |
| Test Range | 0-2000 kN |
| Response Time | <1 second |
| Max Height | Approx. 1100 mm |
| Measuring Range | 0-1000 kN / 0-2000 kN |
| Application | Cement Testing Equipment |
| Usage | Cement Testing Equipment |
| Automation Grade | Semi-Automatic / Manual |
| Interface Type | Digital Interface / Panel controls |
| Power Supply | 220-240 V, 50 Hz, Single Phase |
| Features | Robust pillar design, heavy-duty hydraulic system, precision loading, safety door |
| Number of Specimens | 1 at a time |
| Hardness | Hardened steel platens |
| Port Size | Standard |
| Specimen Size | 150 mm x 150 mm x 150 mm (other sizes with optional platens) |
| Display Type | Digital / Analog |
| Temperature | 10AdegC to 40AdegC |
| Operating Voltage | 220-240 V |
| Accuracy | A+-1% of indicated value |
| Frequency | 50 Hz |
| Product Type | Compression Testing machine Pillar Type |
| Capacity | 1000 kN / 2000 kN |
| Machine Weight | Approx. 450 kg |
| Test Speed | 0.5-5 mm/min (adjustable) |
| Test Width | 200 mm |
| Test Stroke | Up to 100 mm |
| Control Mode | Manual / Automatic |
| Supply Ability | 100 Per Week |
| Delivery Time | 1 Week |
| Sample Available | Yes |
| Sample Policy | Sample costs shipping and taxes has to be paid by the buyer |
| Packaging Details | carton box, export quality also available |
| Main Export Market(s) | Middle East, Asia, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001 ,CE |
Product Overview
Key Features
This machine is quite useful on field Laboratories or mobile testing laboratories or Vans which frequently change site or location. It is particularly useful where constant and consistent Electric power is not available. The load is applied manually and observed on a Pressure gauge. The Pressure Gauge has maximum load indicator which stand still even after the specimen under test crushes and has to be set to zero manually.
Features of Compression Testing machine Pillar Type
High Stability
Self-aligning platen assembly.
Gauges are calibrated in Kilo Newton against certified Proving Ring.
Suitable for testing cubes of various sizes
Using special platens, bricks also can be tested.
Hard chrome plated piston with new type of long life oil seal.
Four Pillar Model " superior in design, reliability and accuracy
Practically no welded parts, all joints reinforced with heavy nut/bolt to withstand occasional over loading and to ensure center loading.
Rounded Corners " add to elegance and safeguard against injury
Hardened and grinded platens with guide lines for placing sample for Testing
