Compression Testing Machine - Accuracy: A 1% Of Indicated Load

Compression Testing Machine - Accuracy: A 1% Of Indicated Load

Get Latest Price

Minimum Order Quantity :

1 Unit

Brand Name :

Edutek

In Stock

Product Specifications

Accuracy	A+- 1% of indicated load
Load Capacity	2000 kN (200 Ton)
Features	Digital Display, Overload Protection, Auto Cut-Off
Control System	Microprocessor Based
Dimension (LWH)	1000 x 600 x 1200 mm
Phase	Single Phase
Sensor	Load Cell Based
Speed Range	0.5 to 5 mm/min (variable)
Color	Blue-Grey
Operating Temperature	5AdegC to 45AdegC
Application	Cement, Concrete Cube or Cylinder Testing
Machine Speed	Adjustable
Product Type	Compression Testing Machine
Screw Size	50 mm diameter
Power	220V AC, 1-Phase
Capacity	2000 kN
Resolution	0.1 kN
Weight	Approx. 600 kg
Frequency	50 Hz
Power Source	Electric
Voltage	220V AC
Stroke Length	220 mm (Platen Travel)
Power Consumption	1.2 kW
Automatic Grade	Other, Semi-Automatic
Material	Mild Steel Body
Payment Terms	Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)
Sample Available	Yes
Sample Policy	Sample costs shipping and taxes has to be paid by the buyer
Packaging Details	carton box, export quality also available
Main Export Market(s)	Asia, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market	All India
Certifications	ISO 9001, 14001 ,CE
