Brushless Motors - High Durability, 110-240v Ac, Compact Design, Energy Efficient | Soft Start, Auto Restart, Adjustable Speed Control
Get Latest Price
In Stock
Product Specifications
| Material | Plastic, Metal |
| Voltage | 12V DC |
| Speed | 3000 RPM |
| Torque | 80gm-cm |
| Dimensions | 61x47.6x64 mm |
| Power | 6W |
| Features | High efficiency, Long lifespan, Quiet operation, Compact design, Reliable performance, Durable construction, Easy installation |
Product Overview
Key Features
With the assistance of our team
of professionals, we manufacture, export and supply the finest quality range of
Brushless Motors. The products offered
by us are highly demanded in the market due to their sturdy construction,
elevated durability, optimum performance and longer functional life. These are
manufactured using quality approved raw materials keeping in mind the international
standards to ensure reliable performance at the usersa end. We assure our
clients that the offered Brushless
Motors are quality assured to meet the clienta s wide expectations.
Applications
- Frost Free Refrigerator
- Evaporator
- Condenser
| Model No | Electrical Source | No Load Typical | Operating Point | ||||||
| Voltage V | Freq Hz | Speed RPM | Current mA | Input W | Output W | Speed RPM | Torque gm-cm | Peak Efficiency | |
| Controller MCON-001 | |||||||||
| MEC162S06A/1AL-NW1 | 110-120V AC | 60Hz | 5600 | 16mA | 1.7 | 0.8 | 2600 | 28 | 44% |
| MEC162S06A/1AL-NW2 | 110-120V AC | 60Hz | 5800 | 27mA | 2.8 | 1.3 | 3000 | 42 | 47% |
| MEC162S08A/1AL-NA1 | 110-120V AC | 60Hz | 4500 | 54mA | 5.6 | 2.7 | 2400 | 107 | 48% |
| MEC162S06A/2AL-NW3 | 220-240V AC | 50/60Hz | 5600 | 9mA | 1.8 | 0.9 | 3000 | 29 | 50% |
| MEC162S06A/2AL-NW4 | 220-240V AC | 50/60Hz | 4800 | 14mA | 2.9 | 1.3 | 3000 | 42 | 46% |
| MEC162S08A/2AL-NA2 | 220-240V AC | 50/60Hz | 4600 | 27mA | 5.6 | 2.7 | 2400 | 109 | 49% |
| Controller MCON-002 | |||||||||
| MEC262S06A/3DL-NW5 | 12V DC |
| 5600 | 0.21A | 2.5 | 1.0 | 2650 | 37 | 41% |
| MEC262S06A/3DL-NW6 | 12V DC |
| 4000 | 0.25A | 3.0 | 1.4 | 3000 | 43 | 45% |
| MEC262S08A/3DL-NA3 | 12V DC |
| 4600 | 0.43A | 5.2 | 2.4 | 2400 | 96 | 46% |
| MEC262S13A/3DL-NE1 | 12V DC |
| 5200 | 1.04A | 12.5 | 6.7 | 2600 | 246 | 54% |
| MEC262S17A/3DL-NS1 | 12V DC |
| 5500 | 1.54A | 18.5 | 9.8 | 2600 | 360 | 53% |
| MEC262S17A/3DL-NS2 | 12V DC |
| 5400 | 2.0A | 24.0 | 12.4 | 2800 | 423 | 52% |
| MEC262S06A/4DL-NW7 | 24V DC | 5600 | 0.1A | 2.4 | 1.0 | 2650 | 37 | 43% | |
| MEC262S06A/4DL-NW8 | 24V DC | 4000 | 0.12A | 2.9 | 1.4 | 3000 | 43 | 47% | |
| MEC262S08A/4DL-NA4 | 24V DC | 4600 | 0.23A | 5.4 | 2.4 | 2400 | 96 | 44% | |
| MEC262S06A/5DL-NW13 | 48V DC | 5600 | 49mA | 2.4 | 1.0 | 2650 | 37 | 43% | |
| MEC262S17A/5DL-NS10 | 48V DC | 5000 | 0.5A | 24.0 | 12.4 | 2800 | 423 | 52% | |
| MEC262S08A/1AL-NA5 | 110-120V AC | 50/60Hz | 4500 | 52mA | 5.4 | 2.8 | 2400 | 110 | 51% |
| MEC262S17A/1AL-NS6 | 110-120V AC | 50/60 Hz | 5500 | 0.25A | 25.4 | 12.4 | 2600 | 456 | 48% |
| MEC262S06A/2AL-NW11 | 220-240V AC | 50/60 Hz | 5600 | 10mA | 2.2 | 1.0 | 2600 | 35 | 43% |
| MEC262S17A/2AL-NS8 | 220-240V AC | 50/60 Hz | 5000 | 0.122A | 25.4 | 12.4 | 2600 | 456 | 49% |
Mechanical Dimension
| Model No | A | B | C | D | E | F | G | H | I | J | K |
| MEC162S06A/1AL-NW1 | 61 | 47.6 | 64 | 3.18 | 30 | 40 | 75 | 34 | 56 | 8 | 7.6 |
| MEC162S06A/1AL-NW2 | 61 | 47.6 | 64 | 3.18 | 30 | 40 | 75 | 34 | 56 | 8 | 7.6 |
| MEC162S08A/1AL-NA1 | 61 | 47.6 | 64 | 3.18 | 29 | 42 | 75 | 34 | 58 | 8 | 7.6 |
| MEC162S06A/2AL-NW3 | 61 | 47.6 | 64 | 3.18 | 30 | 40 | 75 | 34 | 56 | 8 | 7.6 |
| MEC162S06A/2AL-NW4 | 61 | 47.6 | 64 | 3.18 | 30 | 40 | 75 | 34 | 56 | 8 | 7.6 |
| MEC162S08A/2AL-NA2 | 61 | 47.6 | 64 | 3.18 | 29 | 42 | 75 | 34 | 58 | 8 | 7.6 |
| MEC262S06A/3DL-NW5 | 61 | 47.6 | 64 | 3.18 | 30 | 40 | 75 | 34 | 56 | 8 | 7.6 |
| MEC262S06A/3DL-NW6 | 61 | 47.6 | 64 | 3.18 | 30 | 40 | 75 | 34 | 56 | 8 | 7.6 |
| MEC262S08A/3DL-NA3 | 61 | 47.6 | 64 | 3.18 | 29 | 42 | 75 | 34 | 58 | 8 | 7.6 |
| MEC262S13A/3DL-NE1 | 61 | 47.6 | 64 | 6.34 | 52 | 47 | 78.5 | 40 | 57 | 2 | 13 |
| MEC262S17A/3DL-NS1 | 61 | 47.6 | 64 | 6.34 | 59 | 50 | 78.5 | 44.5 | 60 | 2 | 13 |
| MEC262S17A/3DL-NS2 | 61 | 47.6 | 64 | 6.34 | 30 | 50 | 78.5 | 44.5 | 60 | 2 | 13 |
| MEC262S17A/2AL-NS7 | 61 | 47.6 | 64 | 6.34 | 59 | 50 | 78.5 | 44.5 | 60 | 2 | 13 |
| MEC262S17A/2AL-NA8 | 61 | 47.6 | 64 | 6.34 | 59 | 50 | 78.5 | 44.5 | 60 | 2 | 13 |
Class-A Insulation
Impedance protected
Operating Temperature -30 oC to + 60 oC
Humidity 55 oC
Insulation Resistance > 10M A A A a A a A A A A Aca A A a A AC
Additional Features Available
- Soft start
- Auto Restart
- Auto Power down
- Constant speed
- Adjustable speed control
- Intelligent, speed control
