Bernoullis Theorem

We are manufacturing and supplying a big assortment of Bernoulli's Theorem Demonstrator in Ambala Cantt, Haryana, India which facilitates the students and the industrial professionals to explore the fundamentals of a Bernoulli's Theorema in Fluid Mechanics. It states that, in a steady flow the sum of all forms of mechanical energy (kinetic, potential and pressure energy) in a fluid along a streamline is the same at all points on that streamline. It consists of classical venture of clear acrylic. A series of wall tapping allows measurement of static pressure distribution of convergent duct, while a total head tube is provide at the centre of throat. These tapping are connected to a bank of manometer tube. This unit has been designed with Hydraulic Bench to study the characteristic flow through convergent and divergent section.

a cSelf contained system
a cSimple representation of concept
a cDirect measurement of static head
a cSeven pressure tapings along with tubes
a cRequires minimal installation
a cRobust and transparent Venturimeter
a cAll tanks are rust proof

Technical Specifications:-

a cTest Section (Venture)
a c: Throat Diameter - 12mm,
a c: Upstream Diameter - 33 mm
a c: Upstream Taper - 10A
a c: Downstream Taper - 17A
a c: MOC - Acrylic (Transparent)
a cManometer : 0 to 300 mm, Seven Tubes (Flexible & Transparent)
a cReservoir Tan
