Mobile Reversible Drum Concrete Mixer - Rm 800, 12 Cubic Meter Per Hour Output, Hydraulically Operated Weigh Batcher, Digital Water Timer, Heavy Duty Ms Steel Mixing Drum With 4 Mixing Blades

We are extensively known for exporting, trading and distributing our customers BATCHING MACHINE to our clients. Mobile Reversible Drum concrete mixer hydraulically Operated with weigh batcher (Electric Operated) Specifications:
Type: RM 800
Out put : 12 cum/hr
Drum Length: 1880 mm
Drum Diameter: 1350 mm
Prime Movers Electric motor: 12.5 Hp
Pneumatic wheels: 600 x 16 x 4 nos
Loading System: Hydraulically
Hydraulic tank capacity: 35 liters
Drum discharge height : 1500 mm
Weighing with Electronic Load Cell Three Bin : Digital Electronic
Water Timer : Digital Electronic
Supporting legs : 04 nos
MIXING AND DISCHARGE: The reversible drum mixer produces concrete of high quality when the drum is rotating and the mix is discharged when the drum is reversed.
LOADING HOPPER: The loading hopper is fabricated from welded steel plate and strongly reinforced the loading lips. It is raised and lowered through a hydraulic jack and power pack system and the operation is by a single lever.
WATER: Water is controlled through a water pump with auto cut off digital timer is provided in the operation panel for accurate discharge of water into the mixer drum.
MIXING DRUM: The mixing drum is fabricated from M.S.Steel and has 4 mixing blades and two discharge blades and the drum moving on heavy duty m.s.rollers. Gear ring is made of M.S. Steel for extra long life.
