Mix Automatic Wire Threading Stripping Ferrule Crimping Machine

Parameter range:
Suitable terminal specification: 6/8/10mm
Length of peeling: 6-10mm
Crimping range: 0.5-2.5mm (AWG13#-AWG21#)
Pressing ability: 15KN
Gas source: 0.5-0.7Mpa
Power supply: AC 220V 50Hz
Weight: 32kg
Appearance size: 400*340*450mm

Product characteristics:
1. simplification of complex processes can be achieved. The overall efficiency is 3-4 times the original cost, and has a larger cost advantage.
2. the terminals do not need to change the vibratory disc, changing the specifications of different terminals at once.
3. wear thread, peeling and pressing to finish at one time.
4. line deep part uses bell shaped shape to facilitate thread penetration.
5. the peeling line is automatically adjusted, and the height of crimping is automatically adjusted.
6. sensitive pneumatic control should be adopted to press the connection quickly.
