Aerosol Generator

Smoke generator type 210 atomizes liquid paraffin into aerosol through the nozzle, mainly used for smoke alarm and detector sensitivity and function testing. ZNSM210 model aerosol generator built-in brush less pump imported from Germany, brushless pump has the advantages of high pressure, long life, less failure and so on. It is possible to control the amount of aerosol generation by controlling the on-off time of the brush less pump and thus the concentration of smoke in the smoke box.

Smoke generator type 220 atomizes liquid paraffin into aerosol through the nozzle, mainly used for smoke alarm and detector sensitivity and function testing. ZNSM220 model using compressed air to spray aerosol generator, by precision pressure regulator, precise control air pressure, configuration time controller, it can be set through the continuous interval repeat smoke, smoke or cycle through the enactment of on-off time aerosol number, to control the concentration of the smoke cigarette box, can run independently controlled, It has the advantages of high atomization efficiency, long service life, few faults and simple operation.

Comparison of Equipment Parameters

Smoke Generator Model 210

Model: ZNSM210
Power Supply: 12V DC
Power: 200W
Size: 29 cm *A 12 cm *A 23 cm
Standards: EN14604, EN54-7, GB20517, GB4715
Medium: Light paraffin water
Oil Bottle: 100 ml
Smoke Generator Model 220

Model: ZNSM220
Power Supply: 24V DC
Power: 50W
Size: 29 cm *A 12 cm *A 23 cm
Standards: EN14604, EN54-7, GB20517, GB4715
Medium: Light paraffin water
Oil Bottle: 100 ml
