4 Axis Cnc Router Machine - 1500w/2200w Water-cooled Spindle, 300x400x150mm Work Area | High Precision Engraving For Metal, Acrylic, Plastic, Wood

In order to cater the variegated demands of our clients, we are exporting and supplying an excellent quality range of 4 Axis CNC Router Machine in Surat, Gujarat, India. This offered CNC Router Machine is designed and developed utilizing superior grade raw material at vendors well equipped manufacturing unit under the able supervision and guidance of experienced professionals and engineers. Additionally, patrons avail from us a quality tested range of CNC Router Machine that meets their needs and demands in the most promising manner.



Product Details:
Operation Mode : Automatic
Job Material : Acrylic, Metal, Plastic, Wood
Condition : New
Automation Grade : Automatic
HY-3040 Mini Hobby CNC Router 4 Axis parameters
product dimension : 715(H)*700(L)*610(W) mm
effective work area : 300*400*150mm
precision ballscrew : 1605
XYZ rail material : hard chrome shaft
XY rail diameter : 20mm
Z rail diameter : 16mm
XYZ axis torque : 57*78 250 OZ/IN (2.2N/CM)
4th and 5th : 57*56
4th and 5th transmission ratio : 1:6
Repeat positioning accuracy : 0.01mm
Working precision : 0.02mm
Processing speed : 0-4000 mm/min
A-axis B-axis rotation speed : 0-180 rpm/min
XY table maximum load : 50kg
XY+A+B axis table maximum load : 15kg
Tailgate material : stainless steel
Switching power supply : integrated 24V 350W
Spindle power : 1500W/ 2200W water-cooled frequency spindle
Input power : 220V/ 110V power supply
Output current : drive 4.5A (peak 5A)
Collet size : 3/3.175/6mm if need others change into ER11 first
High efficiency water pump : 55W, 46.6L /Min
Drive motor : 57*78 stepper motors (two-phase 4 wire)
Engraving material : Metal,Brass, Acrylic, Wood, Aluminum, Stainless Steel
(Hardness less then 45 degree)
Support computer system : window XP/ window 7
How to connect with computer : 25 pin parallel port
Software : MACH3 3.04
Net weight : 50kg
Packing : wooden box
Outside packing : 78*66*82 (cm)
Weight : 96kg
