33 Kv Potential Transformer

Price:

Get Latest Price

Minimum Order Quantity :

10 Unit

In Stock

Accuracy class	0.5
Dimensions	Variable
Features	Reliable performance, Resilient design, Robust construction, Controlled current, Durable, Cost-effective
Insulation	Epoxy resin
Material	Ceramic, Metal
Mounting	Base mounted
Voltage rating	33 KV
Weight	Variable
Coil Material	Other , Electrolytic Copper
Cooling Type	Air cooled/ Self cooled
Standard	IS 3156 / IEC 60044-2
Capacity	Up to 500 VA
Load Loss	<0.7% of rated burden
Dimension (LWH)	540 x 420 x 250 mm (approx.)
Low Voltage	110 V or user-specified
Operating Temperature	-5C to 55C
High Voltage	33,000 V
Rated Voltage	33 kV
Product Type	Other, Potential Transformer (PT)
Output	Secondary voltage output, standard 110V or 100V as required
Frequency (MHz)	50 Hz (0.05 MHz)
Efficiency	>98%
Phase	Single Phase
Usage	Substation and power distribution measurement and protection
Coil Structure	Other, Toroidal/Cylindrical
Coil Number	Other, Single/Double windings
Power Scope	Voltage Measurement and Isolation
Payment Terms	Cash in Advance (CID)
Supply Ability	100 Per Month
Delivery Time	10 Days
Main Domestic Market	All India
