2000z Computer Control Automatic Upseting Testing Machine

Due to our deep domain adeptness, we are indulged in supplying a qualitative spectrum of 2000z Computer Control Automatic Upseting Testing Machine in Shanghai, China. YQ-Z series upset testing machines is designed according to the international standard "Metallic Materials Upset Test Methods", especially for the quality inspection of high-speed rods and wires. Under room temperature or heated-condition, exert test force in the direction of specimen axial line, quickly compress the specimen, and then inspect the metal ability of bearing upset deformation in the specified upset ratio. It also can show the disfigurements of metal surface.
The YQ-Z series is based on the original model--YQ series. Using the new principle of computer automatic control the sample flattening height replaces using standard block. Greatly reduce the work intensity of operators, improve work efficiency. They are widely used in the steel industry, standard specimen manufacturing industry and tools manufacturing industry for the inspection of the metallic materials upset test.
Specification:
Model and SpecificationYQ-2000Z
Max. Upset Force(kN)2000kN
Max. Shearing Force(kN)Optional:1000
Max. Alignment Force(kN)Optional:150KN/300kN/600KN
Cold Upset Speed(mm/s)60
Hot Upset Speed(mm/s)90
Upset Time(s)0.5
Stroke Adjustment Speed10-100mm/min
Accuracy of Stroke Adjustment5I m
Cold Upset Ratio1/2
Hot Upset Ratio1/3
Speimen for Cold Upset(mm)5-25
Speimen for Hot Upset(mm20-6
