Xlp Cable Testing Equipment - 0-100 Kv Range, 0.5% Accuracy, Semi-automatic, Plc Control, Digital Display, Overcurrent And Overvoltage Protection

Xlp Cable Testing Equipment - 0-100 Kv Range, 0.5% Accuracy, Semi-automatic, Plc Control, Digital Display, Overcurrent And Overvoltage Protection

Get Latest Price

In Stock

In Stock

Product Specifications

Port SizeDN100
FeaturesOvercurrent and overvoltage protection, digital interface, user-friendly operation
Frequency50 Hz
Gas Pressure0.6 MPa
Response Time< 0.5 sec
Operating Voltage380V AC
Number of Specimens1-3 at a time
Accuracy0.5%
Humidity85% RH
Interface TypeRS232/USB
Temperature0 ~ 40C
Max Height2.5 m
Test Range0-100 kV
Power Supply380V/50Hz
Mounting TypeFloor Mounted
Resolution0.01 kV
ApplicationHigh voltage cable insulation testing
Equipment TypeXLP Cable Testing Equipment
Specimen SizeUp to 100 mm diameter
Measuring Range0-100 kV
Automation GradeSemi-automatic
Display TypeDigital Display
UsageIndustrial cable test laboratory
Capacity50 kVA
Machine WeightApprox. 1200 kg
Test SpeedAdjustable (typically 0.5-5 mm/min)
Test WidthUp to 600 mm
Test Stroke600 mm
Control ModePLC Control
