Wheel Alignment Machine - 4200 Kg Capacity Scissors Lift, Patented Quick Clamps & 4d Motorised Measuring Heads For Enhanced Accuracy

Features of Wheel Alignment Machine :
* Measuring Heads : the motorised measuring heads master 4d, installed on the lift, run a guide along the platforms. When not in use, the heads position themselves at the far end of the platforms, to facilitate the placement of the targets on the wheels.
* Targets : The targets installed on the wheels do not include electronic components to avoid any problems if the targets are dropped. Each target is recognised by means of a bar code, thus allowing installation on any wheel.
* Quick Clamps : The wheel clamps supplied with MASTER 4D are patented and enable the installation of the target on the wheel in a safe and quick way.
* Lift : The sturdy 4200 kg capacity scissors lift, grants the utmost planarity. Platform length : 5200 mm
* Flexibility : The position of front plates and rear tables allow to operate on vehicle with a wheel base between 1800 mm and 4400 mm.
* Turn Plates And Rear Sliding Tables : Front turn plates with electronic measurement of the steering angle. Sliding tables with locking in central position and diagnoal/transversal movements in both directions.
