Vp Vfd Input Output Choke

Vp Vfd Input Output Choke

Price:

Get Latest Price

Minimum Order Quantity :

1 Unit

In Stock

In Stock

Product Specifications

InputThree Phase
ComponentsHigh-grade copper winding, core, terminal block
UsageUsed as input and output choke for Variable Frequency Drives (VFDs)
Operating Temperature-10C to +55C
Thermal ConductivityHigh (optimized for heat dissipation)
Response TimeInstantaneous (passive component)
IP RatingIP20
OutputThree Phase
InterfaceTerminal block connection
FeaturesLow power loss, robust construction, compact size, maintenance free
Power SourceElectrical mains
Power SupplyElectric
Product TypeInput Output Choke
ApplicationVFD systems for industrial motor control
Rated Voltage415 V AC
Supply Voltage380-480 V
SizeVariable (based on ampere rating)
Dimension (L*W*H)280 mm x 150 mm x 170 mm (typical)
FunctionReduces harmonic currents, limits voltage spikes, and protects VFD from transient voltages
ColorGrey
Weight6-12 kg (varies by model/power rating)
Capacity1 HP to 200 HP VFD systems
Current Rating10A to 400A
ThicknessCustom/As per application
Frequency50/60 Hz
Payment TermsCash in Advance (CID)
Supply Ability5000 Per Month
Delivery Time10 Days
Main Domestic MarketAll India
