Round Vibrating Screeds Spf Sef

Vibrating Screeds SPF-SEF Series The vibrating screed is used for the surface finishing of prefabricated concrete panel upper layer, produced as moulds. It consists of an aluminium frame formed of two longitudinal, interconnected sections, optionally armoured with an upper steel trestle, according to the length. One or more electric or pneumatic vibrators can be mounted on the screed. Two end handle bars connected by antivibrating supports facilitate the screed movement along the panel. Screeds are also used for vibrating and finishing industrial flooring, airport strips, road dry bridge underlay, etc. In this case, they are supplied with front draft handle bars. Alternatively, turbine vibrator VST 260 for screeds SPF, and 6000 RPM vibrator, 42 Volt, 200 Hz, VEP6 42 200 for screeds SEF may be mounted without any price variation SPF SERIES (PNEUMATIC FEED) Type LengthMt Vibrator WeightKg. Type No SPF 200 2 VSP 618 1 50 SPF 250 2.5 VSP 618 1 60 SPF 300 3 VSP 618 1 70 SPF 350 3.5 VSP 618 2 80 SPF 400 4 VSP 618 2 90 SPF 450 4.5 VSP 618 2 100 SPF 500 5 VSP 618 3 110 SPF 550 5.5 VSP 618 3 120 SPF 600 6 VSP 618 3 130 SEF SERIES (ELECTRIC FEED) Type LengthMt Vibrator WeightKg. Type No SPF 200 2 VEP3 42200 1 50 SPF 250 2.5 VEP3 42200 1 60 SPF 300 3 VEP3 42200 1 70 SPF 350 3.5 VEP3 42200 2 80 SPF 400 4 VEP3 42200 2 90 SPF 450 4.5 VEP3 42200 2 100 SPF 500 5 VEP3 42200 3 110 SPF 550 5.5 VEP3 42200 3 120 SPF 600 6 VEP3 42200 3 130 Alternatively, turbine vibrator VST 260 for screeds SPF, and 6000 RPM vibrator, 42 Volt, 200 Hz, VEP6 42 200 for screeds SEF may be mounted without any price variation
