Uf Membrane Module By Xiner-membrane Meterial Techonology Co., Ltd

Basic parameters of UF Membrane Module: Note: Our product can also be customized by you 1.Model :CN-HUF8040-T5 2.Shell material: UPVC 3.Membrane material: PP or PP composite membrane 3.Dimension(mm): 200*1060 4.Hollow fiber OD(um): 350, 375, 425, 450um 5.Hollow fiber ID(um): 250, 275, 325,350 6.Membrane area(mA ): >75mA 7.Pure water flux: >6.0T/H(0.1Mpa,25C) 8.Molecular Weight Cut off: 50,000D - 80,000D 9.Design water flux: 1.35 - 2.8T/H 10.Max inlet pressure: 0.32 Mpa 11.Operate pressure:0.08 - 0.2Mpa 12.PH range:1-14 13.Temp. range:5 - 45 14. Water turbidity: < 20 NUT 15.Permeate turbidity: < 0.1 NUT 16.Removal rate of SS: 100% 17.Removal rate of bacteria:99.99% 18.System Interface: I 50 loose joint 17.Filtration method: Outside-in and cross flow Features: 1. Outside-in UF Membrane Module. 2. Good hydrophilicity, big water flux. 3. Strong ability of chemically resistant, wide pH range. 4. High strength, long service life 5. Clean easily, good flux restorability. Usage: 1. The pretreatment of RO, NF membrane. 2. Tap water producing. 3. Waste water recycling. 4. Sea water desalination pre-treatment, to protect RO membrane. 5. Biology & Medicine filtration and concentrate. 6. Oil and water separation. 7. Food industry. 8. Power plant, electronic, metallurgy etc.
