Uf Membrane Module - Upvc Shell, 200x1060mm, Pp Membrane, Hollow Fiber 250-350/350-450um | Good Hydrophilicity, Big Water Flux, Wide Ph Range, Long Service Life, Good Restorability, Outside-in Filtration

Basic parameters of UF Membrane Module:

Note: Our product can also be customized by you

1.Model :CN-HUF8040-T5
2.Shell material: UPVC
3.Membrane material: PP or PP composite membrane
3.Dimension(mm): 200*1060
4.Hollow fiber OD(um):350, 375, 425, 450um
5.Hollow fiber ID(um): 250, 275, 325,350
6.Membrane area(mA ):>75mA
7.Pure water flux: >6.0T/H(0.1Mpa,25C)
8.Molecular Weight Cut off: 50,000D - 80,000D
9.Design water flux: 1.35 - 2.8T/H
10.Max inlet pressure: 0.32 Mpa
11.Operate pressure:0.08 - 0.2Mpa
12.PH range:1-14
13.Temp. range:5 - 45
14. Water turbidity: < 20 NUT
15.Permeate turbidity: < 0.1 NUT
16.Removal rate of SS:100%
17.Removal rate of bacteria:99.99%
18.System Interface: I 50 loose joint
17.Filtration method: Outside-in and cross flow

Features:
1. Outside-in UF Membrane Module.
2. Good hydrophilicity, big water flux.
3. Strong ability of chemically resistant, wide pH range.
4. High strength, long service life
5. Clean easily, good flux restorability.

Usage:
1. The pretreatment of RO, NF membrane.
2. Tap water producing.
3. Waste water recycling.
4. Sea water desalination pre-treatment, to protect RO membrane.
5. Biology & Medicine filtration and concentrate.
6. Oil and water separation.
7. Food industry.
8. Power plant, electronic, metallurgy etc.
