Metal Type
Price:
Get Latest Price
In Stock
Product Specifications
| Control Voltage | 4-32VDC |
| Dielectric Strength | 4000VAC |
| Features | High reliability, Fast switching, Compact design, Low power, Stable operation, Long lifespan, Easy installation |
| Isolation Impedance | 1G |
| Load Current | 10-125A |
| Load Voltage | 24-480VAC |
| Operating Temp | -20~+80°C |
| Weight | 100g |
Product Overview
Key Features
Screw Type 1
Main Features
Our company is a reliable manufacturer of Solenoid in Taiwan.
Tai-Shing Electronics Components Corp. is a professional manufacturer of Relays and Solenoids with years of experience. We specialize in manufacturingPower Relays,Solid State Relay, General Relay,Telecom Relay,Tubular Solenoid,Automotive Relay,Latching Relay,Open Frame Solid,Rotary Solenoid and Electromechanical Components Relay. Besides, we also provide Valves and Solenoid Valve with high quality and competitive price. Please feel free to contact us if you are looking for Reliable Signal Relay and DC Solenoid Manufacturer.Main Product:
- Power Relay
- Solid State Relay
- Telecom Relay
- Automotive Relay
- Latching Relay
- Solid State Relay -SSR
- DC Solenoids
- Tubular Solenoid
- Rotary Solenoids
- Water Valves
- DC Voltage Drive AC loading SSR
- High Stable Reliability
- Non Switching Sparks
- Non Noise
- Non Mechanical Contact
- Low control Power Consumption
- High Speed Reaction
ApplicationsIndustrial Control Systems
- Lighting Systems
- Vending Machines
- Production Systems
- Temperature Control Systems
- Electronics Home Appliances
- Medical Equipment
- Conveying Systems
- Ordering Information
-
APPERARANCE
MODEL NO.
SDA-200B010S-1Z / R
SDA-200B015S-1Z / R
SDA-200B025S-1Z / R
SDA-200B040S-1Z / R
SDA-200B050S-1Z / R
SDA-200B075S-1Z / R
SDA-200B090S-1Z / R
SDA-200B100S-1Z / R
SDA-200B125S-1Z / RSDA-400B010S-1Z / R
SDA-400B015S-1Z / R
SDA-400B025S-1Z / R
SDA-400B040S-1Z / R
SDA-400B050S-1Z / R
SDA-400B075S-1Z / R
SDA-400B090S-1Z / R
SDA-400B100S-1Z / R
SDA-400B125S-1Z / RMOUNT TYPE
Screw Type
PHASE
Single Phase
TYPE OF LOAD
Z= Heater load
R= Inductive loadINPUT
Control Voltage Range
4~32VDC
Must Turn Off Voltage
MAX. 1VDC
Input Impedance
1.5 K
OUTPUT
Max. Load Current
10A,15A,25A,40A,50A,75A,90A,100A,125A
Load Voltage Range
24~280VAC
48~480VAC
Min. Blocking Voltage
600VAC peak
1200VAC peak
Max.Off-State Leakage
Less 3mA
Less 5mA
Max.1 cycle Peak Surge
100A,150A,250A,400A,500A,750A,900A,1000A,1250A
Max. Off State dv/dt
500V/sec
1000V/sec
GENERAL RATING
Isolate Impedance
1G
Dielectric Strength
Input-Output
Input , Output-Case
4000VAC RMS
4000VAC RMSTurn On Time
Less 2mA
Turn Off Time
Less 0.5AC Cycle
Frequency Range
47~70Hz
Operating Temperature
-20~+80
Switching Type
Zero Crossing
Random SwitchingOUTLINE DIMENSION(unit:mm)
Weight (g)
100g
Compliance
CE , RoHS
