Torsion Spring Testing Machine - 20Kgcm to 2000Kgcm Capacity Universal Testing for CW & CCW Directions Microcontroller Based Digital Display with Peak Load Feature

This Torsion Spring Testing Machine is without doubt one of the most successful Torsion Spring Testing Machine which is available in Manual Motorized versions. This product is suitable for all types of tensional spring testing for CW & CCW directions. The Digital Display Unit having high reliable microcontroller and high accuracy linear signal converters multiple units Peak Hold multi rotation angle sensing. Capacity range from 20Kgcm to 2000Kgcm. Calibrated from NPL / NABL Lab.

Capacity : 20 Kgcm to 2000 Kgcm
Universal CW & CCW
Least Count (Force) : 0.01 Kccm
Least Count (Deflection) : 0.1A
Measuring Units : NCm KgCm LbInch selectable
Accuracy : + 0.5% of the reading
Display :
(Force & Deflection) : Microcontroller based 6 Digit Digital Display System
Max. Deflection : 1800A
Feature : Peak Load & Buzzer on Overload
Power required : 180VAC to 260VAC @ 50 Hz
Torque applying : Through hand operated rotating wheel
Speed controlled Motorized operation
