Tn100ir Calibration Kit Dimension(l*w*h): 35.5x16.5x10.5 Centimeter (Cm)

Product Specification
Measuring Parameter : Turbidity
Highlights : Light weight, IP67 waterproof meter
Principle : Nephelometric non-ratio / ISO 7027 and DIN 27027 compliant
Range : 0 to 2000 NTU

Automatic Range Selection :
0.01 to 19.99 NTU;
20.0 to 99.9 NTU;
100 to 2000 NTU

Resolution : 0.01 NTU (0 to 19.99 NTU);
0.1 NTU (20.0 to 99.9 NTU);
1 NTU (100 to 2000 NTU)
Accuracy : < 0.1 NTU for 0.02 NTU standard;
A 2 % of reading A 1 digit for 0 to 500 NTU;
A 3 % of reading A 1 digit for 501 to 2000 NTU
Repeatability : < or = A 1 % of reading
Calibration : Up to 4 points
Calibration Standards : 0.02 NTU, 20.0 NTU, 100 NTU, 800 NTU
Response Time : < 6 secs for full step change
Sample Volume : 10 mL
Light Source : Infrared-emitting diode (850 nm wavelength)
Operating Temperature Range : 0 to 50 A C
Sample Temperature Range : 0 to 50 A C
Enclosure Type & Rating : ABS plastic & IP67 rated
Power : 4 x 1.5 V a AAAa alkaline batteries (> 1200 readings)
Certifications/Compliance : FCC part 15 class A, TUV 3 in 1, CE, RoHS
Dimensions (LxWxH) :
Meter: 15.5 x 6.8 x 4.6 cm
Boxed: 35.5 x 16.5 x 10.5 cm
Weight : Meter: 200 g
Boxed: 1,160 g
