Thermal - Cold Cycle Testing Machine - Sus#304 Stainless Steel, 150l Chamber, -70c To +150c | Programmable Plc Touchscreen, Automatic Defrosting, Multi-layer Heated Viewing Window, Mobility Wheels

Name: Thermal - Cold Cycle Testing Machine
Price: 1500.0 USD
Availability: InStock

Price: 1500.0 USD / Unit

Get Latest Price

Minimum Order Quantity :

1 Unit

In Stock

Application	Thermal shock/cycling, material durability assurance
Accuracy	0.5C (temperature), 2.5%RH (humidity - if applicable)
Specimen Size	Max. 400 x 400 x 400 mm
Measuring Range	Configurable as per user requirements
Port Size	Standard: 50 mm, Customizable
Display Type	Digital (Touch Screen)
Number of Specimens	1 to 10 (depending on size)
Response Time	12 min from ambient to max cooling
Equipment Type	Thermal - Cold Cycle Testing Machine
Mounting Type	Floor standing
Resolution	0.1C
Interface Type	RS232/USB
Power Supply	AC 220V/50Hz, Single Phase
Features	Programmable, Over-temperature protection, Viewing window, Mobility wheels
Humidity	20%-98% RH (optional)
Operating Voltage	220V/50Hz
Test Range	-70C to +150C
Gas Pressure	0.4-0.9 MPa (if air supply required)
Frequency	50 Hz
Automation Grade	Automatic
Temperature	-70C to +150C
Max Height	500 mm (internal chamber)
Usage	Laboratory, Industrial Quality Control
Capacity	150 L
Machine Weight	Approx. 450 kg
Test Speed	0.1C/min to 5C/min (adjustable)
Test Width	500 mm
Test Stroke	400 mm
Control Mode	Programmable PLC + Touch Screen
