Switching Power Supply - Adjustable 5v/12v/15v/24v Output | Ac Input Range Selectable, Built-in Dc Fan, Overload & Short Circuit Protection, 100% Full Load Burn-in Test

Following are the Main Features of Switching Power Supply :-
1)AC input range selectable by switch
2)input side chassis plug
3)protections: Short circuit/overload/over voltage
4)forced air cooling by built-in DC FAN
5)PWM control and regulated
6)Built-in cooling fan ON-OFF control
7)100% full load burn-in test
8)Fixed switching frequency at 25kHz

Specification:
Model Ouput Error Range Efficiency
S-35-5 5V, 0-7A A 2% 75mV 70%
S-35-12 12V, 0-3A A 1% 100mV 76%
S-35-15 15V, 0-2.4A A 1% 100mV 78%
S-35-24 24V, 0-1.5A A 1% 100mV 78%

Input:
Voltage range 85-132VAC/170-264VAC by switch 240-370VDC
Frequency range 47-63Hz
AC current 0.8A/115V 0.45A/230V
Inrush Current(max. ) 18A/115V 36A/230V
Leakage current <2mA/240VAC

Output:
DC Adjustable rang A 10%
Over load protection 105-150% hiccup mode, auto-recovery
Over voltage 115-150% hiccup mode, auto-recovery
Setup, rise, hold time 200ms, 100ms, 30ms at full load
