Stepper Motor Drives - Color: Blue And Silver

1. Electrical Specifications:
Input Voltage: 12V to 80V DC (common range; some models go up to 110V)

Current Output: 1.0A to 8.2A peak (adjustable depending on model)

Power Consumption: Typically <100W (varies with load and current setting)

Control Signal Voltage: 3.3V / 5V / 24V compatible (TTL or opto-isolated)

2. Motor Compatibility:
Supported Motor Types: Bipolar stepper motors (2-phase, 4/6/8-wire)

Step Angle: 1.8, 0.9, or other, depending on motor

Microstepping Modes: Up to 1/256 microsteps (common: 1/16, 1/32, 1/64)

3. Control Interface:
Input Signals: STEP (pulse), DIR (direction), ENA (enable)

Pulse Frequency: Up to 200 kHz

Communication (if supported): RS232 / RS485 / CAN / Ethernet / USB

4. Protections:
Over-voltage Protection

Over-current Protection

Over-temperature Protection

Short Circuit Protection

5. Environmental:
Operating Temperature: 0C to 50C

Storage Temperature: -20C to 85C

Humidity: <90% RH, non-condensing

Cooling: Natural convection or external fan

6. Mechanical:
Mounting: DIN rail or panel mount

Dimensions: Vary by model (typically 100 x 75 x 35 mm)

Weight: 200-500 grams
