Static Cone Penetrometer(b) - Diesel Engine Driven, 100 Kn Capacity, 36mm Mantle Tube, 1m Working Length | Ideal For Soil Testing Equipment, 1-2.5cm/sec Penetration Rate

Static Cone Penetrometer
Static Cone Penetrometer Capacity for reaching greater depths and to facilitate easy and constant rate of penetration 1 to 2.5cm/sec of the cone this engine-driven Static Cone Penetrometer of 100 KN (10,000 Kgf) capacity is preferable. The equipment consists of a hydraulic pump driven by a Diesel Engine. The whole system is mounted on a tow able trolley fitted with pneumatic wheels. The pumping unit and ram are connected by means of flexible pipes through a direction control valve. The hydraulic ram moves on a two pillar stand mounted on a trolley

1.Penetration Cone, steel 60 cone angle, 10cm2 base area, with friction jacket One
2. Mantle Tube, 36mm uniform OD with sounding Rod working length 1 m Thirty
3. Load Measuring Head, with Automatic cut-off valve, and oil can without pressure gauges.
4. Pressure Gauge, 0-600 x 5 kg/cm One
5. Pressure Gauge, 0 100 x 1kg/cm One
6. Trusses Two
7. Screw Anchor 45 cm Six
8. Screw Anchor 30 cm Six
9. Screw Anchor 20 cm Six
10. Screw Anchor Rod with cone Six
11. Driving handle for Screw Anchor One
12. Extension Pipe for Handle Four
13. Clamping Screw with Nuts Six
14. Extractor Tube with Connector One
15. Tool Box One

16. Tarpaulin Cover One
