Ss Mixproof Valve

These SS MixProof Valve provides for the safe separation of incompatible fluids in a compact design with significant advantages over traditional block and bleeds installations. By integrating two butterfly discs and independent vent/drain valves into a common housing, the mix proof butterfly valve completely isolates the cleanable leakage chamber with a single valve housing and actuator.

Technical parameters of SS MixProof Valve :
Material pressure range: 0 ~ 8 bar
Operative temperature range: -10deg C ~ +150deg C
Operative air pressure: 6 ~8 bar
Material: Material contact parts: SS 304 or SS316L
Sealing material: Standard EPDM silica gel, fluorine gel for option.
Surface treatment: Outside: Sandblast Ra up to 1.6Aum
Sublight Ra up to 0.6Aum
Inside: Polish up to 0.6Aum

Requirements for compressed air quality for actuator:
Compressed air joint: R1/8a
Max grain size: 0.01mm
Max oil content: 0.08ppm
Dew point: below 10 deg C or less
Max water content: 7.5g/kg
