Slq Primary Current Injection Test Machine

Introduction
SLQ is essential equipment used for electrical debugging to generate high current, which be widely used in power plants, power distribution stations, electrical plants, scientific research, laboratories and other units. It is a short-term or intermittent work device and characterized by small size, light weight, good performance, easy use and maintenance

Features:
1. Two ammeters, can supervise different measurement range.
2. Auto transformer adjusts freely.
3. with indicator lighting and button, easy to operate
4. Incorporated and dividable structure, easy to move.

Parameters:
The equipment capacity is designed based on 5-minute short-term work system. For intermittent work, working time should be less than 2.5 minutes, before continuing to work it should be shut down for 10 minutes so that all parts of the machine can cool down. Specifications and technical parameters as follows:

ModelCapacity (KVA)Junior RangeSecondary RangeDimension (mm)LA WA HWeight(kg)Remark
V1A1V2A2
SLQ-5003220156500430A 338A 55048Integrated structure
SLQ-100062202761000500A 380A 60080Integrated structure
SLQ- 25001538039.562500600A 430A 790145Integrated structure
SLQ- 4000243806364000640A 450A 820180Integrated / split
SLQ- 5000303807965000
600A 430A 900
300A 500A 500
145
135
Split Structure
SLQ- 6000363809566000
600A 430A 900
300A 500A 500
150
140
Split Structure
SLQ- 80004838012668000
600A 450A 950
350A 550A 550
180Split Structure
SLQ- 10000
60

380
158610000
800A 600A 1100
380A 550A 600
200Split Structure
