Simulation Test Dummy Iso 6487 Standard - Aluminum Titanium Alloy Skeleton, 1699mm Height, Modular Joints, Real-time Data Output
Price: 800.0 USD / Unit
Get Latest Price
Minimum Order Quantity :
1 Unit
In Stock
Product Specifications
| Automation Grade | Semi-automatic/fully automatic, as specified |
| Operating Voltage | 12V DC for sensors, 230V AC for system |
| Test Range | Multiple positions (standing, kneeling, prone) |
| Number of Specimens | 1 dummy per test |
| Port Size | Standard instrument/computer connection ports, USB/Ethernet (as per installation) |
| Resolution | 16-bit data acquisition recommended for transducers |
| Max Height | Approx. 175 cm |
| Mounting Type | Floor stand or integrated test sled |
| Equipment Type | Simulation Test Dummy |
| Frequency | Sensors sampled at 10 kHz minimum |
| Accuracy | High, conforms to ISO 6487 measurement accuracy standards |
| Interface Type | USB, CAN-bus, Ethernet |
| Response Time | <1 ms data acquisition system |
| Features | Modular joints, replaceable limbs, real-time data output, ISO 6487-compliant measurement points |
| Power Supply | 230V AC, 50/60 Hz |
| Gas Pressure | Not applicable for standard dummy; optional for pneumatic actuation features |
| Hardness | Skin/flesh simulants: shore hardness 25-35A; bone structures: comparable to human bone |
| Temperature | Operating range: 0C to 50C |
| Measuring Range | Full body (head, torso, limbs) as per ISO 6487 instrumentation capability |
| Specimen Size | Adult 50th percentile male, approx. 175 cm height |
| Display Type | Digital interface (PC or dedicated display) |
| Application | Crash testing, safety systems evaluation, impact biomechanics research |
| Humidity | Operating range: 20% to 80% RH (non-condensing) |
| Usage | Automotive safety laboratories, research centers, certification agencies |
| Capacity | Single test per sequence, repeatable |
| Machine Weight | Approx. 75 kg (varies by dummy model) |
| Test Speed | Up to 60 km/h (customizable for specific tests) |
| Test Width | Standard width 45 cm (shoulder breadth of adult dummy) |
| Test Stroke | Variable, typically up to 2000 mm |
| Control Mode | Manual/Automatic (software controlled with test sequence programming) |
